TKLB Live Bottom

Page 1

Page 2

Page 3

Page 4

Lift Cylinders Front to Back Tarps Aluminum cylinders are corrosion resistant optional available with a manual or electric drive Lightboxes LIVE BOTTOM Mounted independently above gearbox covers Bolt On Front Fenders Low maintenance protection LOOKING FOR MORE Navigate to www trailking com and click on the SOLUTIONS tab Each product page includes specifications video literature images services information and our official color card Pin Style Landing Optional two speed landing legs also available SAFE FAST UNIFORM MORE EFFICIENT DELIVERY Front Bearing Assembly Heavy duty outboard design for easier maintenance Exterior Mounted Lines Air electrical mounted standard w aluminum covers or optional stainless steel Chain Oiler Brushes Located at front idler for better oil distribution accessibility Designed for strength and speed this live bottom delivers Our innovative TKLB distributes weight to maximize your payload and maintain high levels of maneuverability with multiple axle configurations Electric Cab Control standard with rear over ride Flip Up Mud Flaps Convenient hinged design for better paver hopper clearance Optional auto flip up Hydrostatic Drive Single or dual direct hydrostatic drive w double reduction planetary gearbox and drive tube The frictionless drive system provides efficient horizontal discharge while unloading in one revolution or less The aerodynamic design features smooth side panels providing corrosion prevention and a clean shiny finish This trailer will provide a high level of return on your investment with consistent performance Heavy Duty Roller Chain 4 pitch chain with frictionless z bar design Sprocket chain guide profile capable of reversing option Exterior Sheeting Side wall flat front wall aluminum or stainless steel insulation optional attached to steel body with high strength adhesives Upper Coupler King Pin Bolt on design allows for simpler maintenance and better access Aluminum Spray Tank Find your nearest rep www TrailKing com find a rep LOOKFORTHETRIANGLES Pressurized with large relief cap Regulated to adjust pressure with 30ft of hose nozzle Cast Steel Mountings Round hopper cross members attached to sidewall with cast steel mountings Hopper Walls Constructed with longer lasting 160 4mm thick AR450 wear plate rear half standard full length optional

Page 5

PROTECT YOUR INVESTMENT OVER 30 YEARS OF LIVE BOTTOM EXPERIENCE From financing a trailer to a complete refurbishment at our Factory Service Center Trail King is there to keep your team hauling day in and day out Our trusted network of dealers and certified experts are ready to assist you Trail King has been delivering dependable asphalt and asphalt related material hauling solutions to the paving industry since 1987 longer than any other trailer manufacturer 226 102 MATERIALS HAULING 236 96 A A B B KEEP YOUR TEAM HAULING Instantly access over 10 000 on hand parts and a variety of online tools All Trail King Certified dealers fleets and service facilities can place same day shipping orders for convenient and efficient ordering Customers looking for more information can contact a local Trail King dealer or submit direct inquiries to parts trailking com C C D D 336 102 426 102 A A PROTECT YOUR INVESTMENT Extend the life of your trailer and increase future resale value by restoring it through Trail King s factory refurbishment program Customers can request a free estimate for comprehensive refurbishments or specified repairs by visiting trailking com refurb service Our expert technicians specialize in Trail King equipment but we also welcome other trailer brands B B C C D D 332 102 440 102 A B A 100 EQUIPMENT FINANCING Competitive rates and flexible terms are designed to make a Trail King purchase affordable convenient and secure Trail King s innovative payment program operates with an understanding of the changing demands businesses face Our full suite of financing structures including Loans Finance Leases and TRAC Leases makes it easier than ever before to own a Trail King trailer B C C D D TKLB SPECIFICATIONS MODEL Capacity Overall Length A Overall Height B Overall Width Number of Axles Empty Weight 3 King Pin Height C King Pin to Center of Last Axle D 226 102 426 102 332 102 24 cu yds 31 2 9 4 24 cu yds 31 2 9 4 102 4 15 130 lbs 49 25 11 29 cu yds 37 2 9 4 102 3 15 170 lbs 49 31 11 102 2 12 000 lbs 49 25 11 OTHER POPULAR OPTIONS Tarp systems manual and electric Aluminum or Stainless sheeting insulation Air lift suspensions Flow control valve Pressurized 12 gal spray system aluminum tank Paint options 236 96 336 102 32 cu yds 28 cu yds 41 2 41 2 9 4 8 11 96 body 102 102 3 2 15 570 lbs 13 300 lbs 49 49 35 11 35 11 TRAIL KING IS 440 102 BUILDING SUCCESS Trail King Industries Inc headquartered in Mitchell SD is the leading manufacturer of open deck and materials hauling trailers for the asphalt paving construction commercial hauling agriculture and specialized transport industries 35 cu yds 45 2 9 4 102 4 17 230 lbs 49 39 11 Over the years Trail King has always kept one thing a top priority our customers success Our trailers are customized for unique challenges and together we can create a solution that is just right for your team We don t just build trailers We design hauling solutions See your local dealer for a full list of available options Multiple axle configurations Air Ride suspensions Gravel service belt in lieu of heat and oil resistant Plastic half round rear fender options Tire and wheel options Dual drive system All specifications are subject to change without notice Trailers pictured in this brochure may feature optional equipment Contract 092922 TKI trailking com TKLB 300 East Norway Ave Mitchell SD 57301 800 843 3324 trailking com 2023 Trail King Industries All rights reserved TKLB LIVE BOTTOM
